Auto impurity removal
316SS auto-drain tank
High purity gas circuit
Precise dual pressure
Easy desiccant swap
Comprehensive safety
Equipped with HL-A device to automatically adsorb and remove hydrocarbons, esters, oils and other impurities in air for improved air quality, and it is maintenance-free.
The air storage tank is made of 316 stainless steel with automatic drainage function, which avoids yellow rust water discharge and laboratory contamination.
All gas pipelines are stainless steel tubes processed by electrolytic polishing and ultrasonic cleaning, which effectively improves air purity.
Equipped with dual filters, three-stage purification and two-stage pressure stabilization to achieve high precision of output pressure.
Complete protection devices are configured, including safety valves and high-precision, high-sensitivity pressure controllers.
Stainless steel drying tubes are adopted to prevent damage caused by material aging and eliminate abrasion risks from repeated disassembly.
A vent valve is installed. There is no need to disassemble the outlet for pressure relief when replacing desiccants; just open the vent valve directly for fast and convenient operation.
| Instrument model QP-Plus | A3L | A5L |
| Maximum output flow | 3 L/min | 5 L/min |
| Output pressure | Output port A: 0.4MPa Output port B: 0.4MPa | |
| Export specifications | M8×1, aperture φ3.3 | |
| Air quality | Oil-free, dry, three-stage purified clean gas | |
| Particulate matter | 0.01um | |
| Drying method | Adsorption drying/silica gel | |
| Noise | < 40db | |
| Working power supply | 220V/50HZ | |
| Environmental conditions | Ambient temperature: 0-35℃; Relative humidity: ≤85%; No large amounts of dust or corrosive gases; Good ventilation; No direct sunlight. | |
| Maximum power | 180W | 250W |
| Dimensions: Length × Width × Height (mm) | 550mm*305mm*425mm | |
| Weight KG | 27KG | |
Flame Ionization Detector (FID) Support Air
Electron Capture Detector (ECD) Auxiliary Air
Flame Photometric Detector (FPD) Combustion Air
Nitrogen Phosphorus Detector (NPD) Combustion Air
GC Column Purge & Carrier Auxiliary Gas
Headspace Sampler Pneumatic Drive Air
Atomic Absorption Spectrometer (AAS) Fuel Support Air
Inductively Coupled Plasma Optical Emission Spectrometry (ICP-OES) Auxiliary Air
Fourier Transform Infrared Spectrometer (FTIR) Purge Gas
UV-Vis Spectrophotometer Cabinet Purge
Thermal Analyzers (TGA/DSC) Protective Purge Air
Total Organic Carbon Analyzer (TOC) Combustion Air
Elemental Analyzer Carrier Auxiliary Air
Sample Concentrators
Sample Evaporators
Cell Incubators
IVF Stem Cell Incubators
Mask Aligner
Fume Hood / Cabinet Purge
3D Printer Inerting Auxiliary Air
Glove Box Purge Air
Laboratory Pneumatic Equipment
Microscope Environmental Chamber Purge
